Product Parameters |
||||
Product name |
CNC machined parts Turning and milling parts |
|||
Processing technology |
Turning,Milling,Planing,Grinding,Drilling,Etching / Chemical Machining |
|||
Heat treatment |
Annealing, Normalizing , Nitriding, Tempering , Carbonitriding |
|||
Material |
Stainless Steel: SS201,SS301,SS303, SS304, SS316, SS416 etc. Steel: mild steel, Carbon steel, 4140, 4340, Q235, Q345B, 20#, 45#etc. Aluminum: AL6061, Al6063, AL6082, AL7075, AL5052, A380 etc. Brass: HPb63, HPb62, HPb61, HPb59, H59, H68, H80, H90 etc. Copper: C11000,C12000,C12000, C36000 etc. Plastic: ABS, PC, PE, POM, Delrin, Nylon,PP, Peek etc. Other: Titanium,etc. We handle many other type of materials. Please contact us if your required material is not listed above. |
|||
Surface Treatment |
Stainless Steel:Polishing, Passivating, Sandblasting, Laser engraving,Oxide black,Electrophoresis black Steel: Zinc plating, Oxide black, Nickel plating, Chrome plating, Carburized, Powder Coated, Heat treatment. Aluminum:Clear Anodized, Color Anodized,Sandblast Anodized, Chemical Film,Brushing,Polishing. Brass: Nickel plating,chrome plating,Electrophoresis black,Oxide black,Powder coated. Plastic:Plating gold (ABS), Painting, Brushing (Acylic), aser engraving. Anodizing, Sandblasting, Metal Plating, Polishing, Painting, Powder coating, Brushing ,Silk-screen , Laser Engraving etc. |
|||
Application |
All kinds of cars,machinery,home appliance,electronic products,electric appliance,stationery,computers,power switches,miniature switcher,architecture,commodity and A/V equipment,hardware and plastic molds,sports equipment and gifts,and more. |
|||
Testing Machine |
CMM,Digital Height Gauge, caliper, Coordinate measuring machine, projecter machine, roughness tester, hardness tester and so on |
|||
Delivery time |
7-10 days for sample, 10-25 days for bulk order |
|||
Capacity |
CNC turning work range: φ0.5mm-φ150mm*300mm CNC milling work range: 510mm*1020mm*500mm |
|||
Packaging Details |
Carton + pallet or Plywood cases or Other package as per customer requirement |
|||
One-stop Service |
Custom Design, Fabrication, Assembly And Delivery |
Hongsinn's Five-Axis Machining Services
Hongsinn's five-axis machining services offer unparalleled speed and flexibility. With a wide range of advanced five-axis CNC machines and a wide variety of materials, we are able to provide the best five-axis machined parts.
Experienced Team: Our team has extensive experience in rapidly designing and manufacturing complex and time-sensitive components.
World-Class Equipment and Expertise: Combining cutting-edge equipment and specialized skills, Hongsinn utilizes two exceptional setups to ensure the production of precise and complex parts.
Five-Axis CNC Machining
Five-axis CNC machining is an advanced manufacturing process that enables the tool to move simultaneously along five different axes. This capability is crucial for producing complex, high-precision parts with greater efficiency and reduced setup time. Industries such as aerospace, automotive, and medical device manufacturing rely on five-axis machining services to create complex components requiring extreme precision.
5-Axis vs. 3-Axis Machining
In CNC machining, choosing a 3-axis or 5-axis system significantly impacts production capacity. 3-axis machining operates along the X, Y, and Z axes and is suitable for manufacturing simple, flat parts. Due to its efficiency and lower cost, 3-axis machining is commonly used in industries such as automotive, construction, and aerospace.
In contrast, 5-axis machining adds two rotary axes, allowing the tool to cut from multiple angles and is ideal for creating highly complex parts with intricate geometries. Such systems are preferred in fields such as aerospace, medical, and advanced automotive manufacturing, where precision and tight tolerances are paramount.
While 5-axis systems involve a higher upfront cost, they offer higher production efficiency by reducing the need for multiple setups and the chance of human error. Ultimately, 3-axis machines are ideal for basic designs, while 5-axis machines excel at producing complex parts requiring higher precision.
FAQ:
1. Can I get a quote without drawings?
Sure, we appreciate to receive your samples, pictures or drafts with detailed dimensions for accurate quotation.
2.Will my drawings be divulged if you benefit?
No, we pay much attention to protect our customers’ privacy of drawings, signing NDA is also accepted if need.
3. Can you provide samples before mass production?
Sure, sample fee is needed, will be returned when mass production if possible.
4. How about the lead time?
Generally, 1-2 weeks for samples, 3-4 weeks for mass production.
5. How do you control the quality?
(1) Material inspection--Check the material surface and roughly dimension.
(2) Production inspection--Each production section will check the key dimensions and appearance.
Before surface treatment, do a good job of product packaging to avoid bumps and injuries. And check visual inspection
(3) Sampling inspection--Check the quality before sending to the warehouse.
(4) Pre-shipment inspection--100% inspected by QC assistants before shipment.
6. What will you do if we receive poor quality parts?
Please kindly send us the pictures, our engineers will find the solutions and remake them for you asap.
